Crosshill 2.0
Crosshill 2.0
Description
Que comience la aventura (de nuevo). No des media vuelta cuando se acabe la carretera. Descubre un sinfín de posibilidades y traza una nueva ruta con la Crosshill, la primera bicicleta de gravel de Lapierre. Esta bicicleta es una invitación a la aventura; pasa del asfalto a los senderos y déjate llevar por lo que te depare el camino. Divertida, cómoda y fácil de manejar gracias a su plato único y sus frenos de disco, la Crosshill ha sido diseñada para viajar y dar rienda suelta a la aventura.
Geometry
| Component | XS | S | M | L | XL |
|---|---|---|---|---|---|
| A: Seat tube length (mm) | 420 mm | 460 mm | 500 mm | 550 mm | 600 mm |
| B: Top Tube legth (mm) | 525 mm | 544 mm | 561 mm | 579 mm | 596 mm |
| C: Head tube length (mm) | 90 mm | 120 mm | 150 mm | 180 mm | 210 mm |
| D: Head Tube Angle | 70 degrees | 70.5 degrees | 71 degrees | 71 degrees | 72 degrees |
| E: Seat Tube Angle | 73 degrees | 73 degrees | 72.5 degrees | 72.5 degrees | 71.5 degrees |
| F: Chain stay length (mm) | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| G: Wheelbase (mm) | 1004 mm | 1020 mm | 1028 mm | 1047 mm | 1053 mm |
| H: Stack (mm) | 517 mm | 547 mm | 606 mm | 606 mm | 636 mm |
| I: Reach (mm) | 367 mm | 377 mm | 379 mm | 388 mm | 389 mm |
| K: Bottom bracket drop (mm) | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
Specifications
e-System
e-System
Battery:
Charger:
Display:
Motor:
Frame
Frame
Frame: HIGH Aluminium Uni
Modular Rail System:
Maximum loadable weight: 110 kg
Drive
Drive
Cassette: Shimano CS-LG300-10, HG
Chain: KMC eGlide with EPT Coating 9-11s
Crankset: CUES FC-U6010-2, HOLLOWTECH 2
Derailleur Rear: Shimano CUES RD-U6020 10s, Shadow
Gear: Shimano Derailleur
Number of gears: 20
Shifter Right: Shimano Shift-brake lever CUES ST-U6030-R Dual Control-Lever
Suspension
Suspension
Front Fork: Lapierre Rigid CarbonFlatmount
Travel:
Shock:
Damper:
Rear Travel:
Components
Components
Front Brake: Shimano Hydraulic Disc brake CUES BR-U6030, 2 pistons, resin pad, 160 mm
Rear Brake: Shimano Hydraulic Disc brake CUES BR-U6030, 2 pistons, resin pad, 160 mm
Headlight:
Rear Light:
Brake light:
Grips: XLC BT-G40 Elastomertape
Handlebar: Lapierre Drop bar JD-RA120A Gravel Bar, Dia. 31.8 mm, 16° flare
Pedal: XLC PD-R01 Race w.Reflector
Saddle: XLC MTB Sport SA-S10 143 mm
Seatpost: XLC Non Suspension SP-R30, Dia. 27.2 mm, L: 350 mm
Wheelset
Wheelset
wheel set:
wheel set:
Rim: XLC WR-M19 Disc 25/622, 32H, 6,5 mm Valve
Tyre: Mitas X-Road, Skinwall, 60TPI 42-622
*The above illustration is for example purposes only. The manufacturer reserves the right to replace individual components shown with equivalent or higher-quality components, provided that the type, suitability and intended use of the bicycle are not impaired, meaning that the bicycle delivered may differ accordingly. The use of other components is currently mainly due to delivery problems.
