Description
Specifications
e-System
e-System
Battery:
Charger:
Display:
Motor:
Frame
Frame
Frame: HIGH Carbon Gents
Modular Rail System:
Maximum loadable weight: 120 kg
Drive
Drive
Cassette: Shimano Cassette Deore CS-M6100-12, MICRO SPLINE
Chain: Shimano Chain CN-M6100 12s
Crankset: Deore XT FC-M8120 Crankset
Derailleur Rear: Shimano Deore XT RD-M8100-SGS 12s, Shadow +
Gear: Shimano Derailleur
Number of gears: 12
Shifter Right: Shimano Triggershift Deore XT SL-M8100-R, Rapidfire+
Suspension
Suspension
Front Fork: FOX Factory 34 Float SL F-S Grip SL, 120 mm
Rear Travel:
Shock: FOX Factory Float Factory Series, 210x55 mm
Travel: 120 mm
Components
Components
Front Brake: Shimano Hydraulic Disc brake Deore XT BR-M8100, 2 pistons, resin pad, 180 mm
Rear Brake: Shimano Hydraulic Disc brake Deore XT BR-M8100, 2 pistons, resin pad, 160 mm
Headlight:
Rear Light:
Brake light:
Grips: Lapierre VLG-1866-11D2
Handlebar: Race Face Flat bar TURBINE, Dia. 31.8 mm, Rise: 15 mm
Pedal: XLC VPE-527
Saddle: Fizik MTB Vento Argo X 140 mm
Seatpost: Limotec Dropperpost A1 Light Dropper, Dia. 31.6 mm, Travel: 100 mm 345 mm
Wheelset
Wheelset
wheel set: DT Swiss XR 1700 Spline, 25 mm, 15x110 mm, CL
wheel set:
Rim:
Tyre: Maxxis Ardent Race 3C MaxxSpeed EXO TR 2.35 120 TPI 60-622
*The above illustration is for example purposes only. The manufacturer reserves the right to replace individual components shown with equivalent or higher-quality components, provided that the type, suitability and intended use of the bicycle are not impaired, meaning that the bicycle delivered may differ accordingly. The use of other components is currently mainly due to delivery problems.
